5 Ton cylinder, single acting, 5" stroke - threaded rod end and base

5 Ton cylinder, single acting, 5″ stroke – threaded rod end and base

$424.95

5 Ton cylinder, single acting, 5″ stroke – threaded rod end and base

In stock

SKU: CA5-5 Category:

5 Ton cylinder, single acting, 5″ stroke – threaded rod end and base

PowerX automotive cylinders are designed to meet your bending, pushing, and holding application needs. These robust, high quality cylinders are designed with collar and base threads that allow for easy customization for your specific application.

  • Single Acting with spring return
  • Collar and base threads accommodate accessories and adapters
  • 3/8” NPTF high flow coupler with dust caps
  • Roll Burnished Cylinder increases seal life
  • Durable exterior finish and ANSI B30.1 compliant
  • Rod end saddle, available as an option
*Contact us for higher tonnage or longer stroke cylinders.
Weight 5 lbs
Dimensions 11 × 5 × 3 in
Base Thread

3/4 – 14 NPT
Rod Thread

3/4/2016
Minimum Height (in)

9.28
Capacity (Tons)

Maximum Height (in)

14.28
Stroke (in)

5

Cross Reference Part Numbers

Manufacturer Part Number
PowerXCA5-5
BVA HT0405
Ram-Pac RC-4-5A-SA
Simplex -
Power Team C55CBT
Enerpac -
